Universal substrate (glass composite single-sided / 95 x 138 x 1.6t) (ICB-97-CK)

D-sub connector can be directly mounted

• Universal Printed Circuits Boards
• Universal Printed Circuits Boards
• RoHS compliant
• Glass Composite (CEM-3)
• Single-sided
• 2.54mm

Prices have been revised effective July 1, 2023.

The ICB-97 size board is pre-patterned and pre-wired for direct mounting of a 9-pin D-sub connector and a DC jack. This eliminates the need for a conversion board when connecting a microcontroller IC to a PC via serial communication.

Main Specifications

Model No.

ICB-97-CK

RoHS directive (10 substances)

Compliant

Material types

Glass Composite (CEM-3)

Double-sided / Single-sided

Single-sided

Pitch

2.54mm

Body size

95 x 138 x 1.6t (mm)

Quantity

1 piece

Product size (including packaging, approx.)

120 x 175 x 10 mm

Weight (including packaging, approx.)

39g

JAN code

4931442009749

Country of origin

Japan

Hole diameter

1.0 dia.

Pattern / Land shape

For Dsub + dot pattern

Finishing Treatment

Flux, Silk printing on component surface

Accessories (Contents of set)

DC jack (Hosiden HEC0470-01-630 (2.1Φ) or equivalent) x 1, One-touch board stand MPS-08 (4 pieces) x 1

icb97ck

Documents related to this product

• Detailed drawing of universal substrate (glass composite single-sided / 95 x 138 x 1.6t) (ICB-97-CK)
• Universal substrate (glass composite single-sided / 95 x 138 x 1.6t) (ICB-97-CK) RoHS certificate
